Flexline Quantum CryoCycling Chambers

Thermal shock testing extended to cryogenic temperatures. For testing novel materials, semiconductor chips, Quantum devices such as qubits, advanced laser media, superconductors and focal plane arrays. Custom vacuum chambers cooled by combination of nitrogen and helium in both liquid and gas phases.

Testing Capabilities

  • Temperature Ranges

    • Standard +200°C to -185°C [88K]

    • Extended +200°C to -248°C [25K]

    • Quantum +200°C to -267°C [6K]

  • Rapid Thermal Shock Chamber

    • ± 20°C per minute

  • Temperature Stability

    • ± 2°C above -190°C

    • ± 1°C below -190°C

  • Large UUT ~ 20 pounds, 400 mm diameters

  • Custom Vacuum Chamber, 1E-10 torr

  • Direct part connection (cooling lines) or bolted to a cooling block

  • Closed Circuit cooling with Liquid Nitrogen and Helium

Chamber Compatibility

  • Integrated Circuits and FPGA

  • PCBs

  • Qubits

  • Cryogenic Laser Media

  • Focal Plane Arrays

  • Superconductors

3D CAD rendering of industrial machinery with a large cylindrical tank, central processing chamber, control panel, monitor, and electronic equipment
